This VW T5/6 kit has been designed and pre-scribed to fit perfectly flush, straight into your camper van, minimising work and saving a huge amount of time.
With our clever integrated floor system, you can build your units with ease, simply click pieces into the rebated floor base, prewire and install any appliances, then simply push the units back and fit
The flush design of the worktop sink/ grill and handle less door option combines the modern look with the tradition real wood feel. The beauty of our concept has changed the small van conversion concept all together, allowing you to remove the units if necessary.
Spec.
High pressure laminated birch
Solid oak work top and folding table
Real oak tambour door
Integrated floor system for simple installation
Soft close drawer
Soft close door hinges
Overhead LED top locker
Full size window surround splashback
Full LED shelving system throughout
Kickboards for Rock ‘N’ Roll Bed
Table with folding leg & rail
Table storage system
LED cubby hole
Worktop storage flap
Grill/sink cut outs with flush design
Easy to follow picture instructions
SWB Overall length: 2180mm | Height 1340mm
LWB Overall length 2580mm | Height 1340mm
Work top Height: 760mm
Fridge Aperture Width: 390mm | Height 536mm Will accommodate most popular campervan 12v fridges
Rock & Roll bed Suitable for beds 112cm or smaller
Van floor Must have an overall thickness no greater than 16mm from the ribs
Plug and Play Features
ReVace 50l 12v compressor fridge
Smev dometic 9722 hob/ sink combination with Piezo ignition
Step by step instruction manual and electrical diagram
Fully pre-wired electrical loom
CTEK D250SE split charge with duel solar input
Victron energy blue smart IP65 charge
complete 240 mains hook up kit
Exide AGM 95ah leisure battery
Dimatec Florenz water tap
Water pump
2 x 12l water tanks
2 x C-line control panels with the below…
USB & built in voltmeter/ main light touch dimmer switch/ 240 plug/ 1 x cupboard
